Description
Wharfedale Pro Connect 802 USB Mini Mixer with USB
Connect 802 USB from Wharfedale Pro is a compact mixing desk with massive capabilities. If you need a portable mixing desk and you do not want to sacrifice space for connections we have managed to condense ample inputs, outputs, and other digital features into a slim, small footprint mixer which is at home in the studio as it is the road.
Key Features | Wharfedale Pro Connect 802 USB Mini Mixer
8 Total inputs (2 x XLR / 6.3mm Jack, 2 x twin 6.3mm jack)
2 x 6.3mm jack outputs
Studio grade phantom power XLR connections
16 bit / 48kHz built in USB audio interface
Playback and record via USB audio interface
Headphone output
Pan / Balance control
Clip LED display
Ideal for home studio recording and live use
slimline profile for portability and to fit in gig bags
Leave the large mixer behind
The connect 802USB is the ideal companion for small-scale live performances and discreet sound installations where there simply isn’t space for a full-scale mixing desk. While packing a wealth of features for mixing and recording it does so with a small footprint. The use of rotary controls as opposed to larger linear faders means space is saved to fit the mixer into small spaces even including guitar gig bags, yet the textured rotary pots operate with a suitable resistance so EQ and level controls can be pin-pointed with accuracy.
Small Size, Studio Sound
The Connect 802USB features two studio grade XLR / Jack inputs with phantom power and two additional stereo channels. This makes the mixing desk particularly well suited to singer-songwriter musicians who maybe using their vocals combined with a guitar and backing tracks and small band setups. There is also a headphone output for studio-style monitoring.
USB Audio Interface
With a built-in USB audio interface, this latest series enables a stereo in/out which can be used for playback of audio files from your PC or Mac, and can also record the master output of your mixing desk. 16-bit / 48 kHz recording ensures CD quality for your audio, whether working in a live or studio environment.
Wharfedale Pro Affordability and Quality
As with all Wharfedale Pro products, the Connect Series are competitively priced yet maintain the essentials of a high-quality mixing desk. High headroom, low noise operation ensures a professional sound and integration with any sound system. The Wharfedale Pro Connect 802 USB Mini Mixer is competitively priced and yet maintains the essentials needed in a high-quality mixing desk.
SPECIFICATIONS | Wharfedale Pro Connect 802 USB Mini Mixer
Channels 6
Inputs 2 x XLR, 6 x 6.3mm jack
Outputs 2 x 6.3mm jack
Headphone Output 6.3mm jack
EQ 3 Band
Phantom Power Yes
Signal To Noise Ratio >78dB ±5dB @ Max Gain
Frequency Response 20Hz-20kHz ±2dB
Display Dual 4-Segment LED
Dimensions: (H x W x D) 50.9mm x 208mm x 183.8 mm
Weight 0.92kg / 1.9kg
